113mm AC Oil Cooling Drum Motor



Cylinder
"The standard cylinder is made of mild steel and coated with anti-rust oil
Food grade cylinder is 304 stainless steel
Standard cylinder surface is treated with non-slip thread"

Gear Drive
"High-alloy steel precision-ground gears ensure ultra-low noise during transmission
Die-cast aluminum gearbox"

Motor
"When the frequency is 50Hz or 60Hz, it is suitable for various universal voltages around the world
Motor insulation class F
Additional thermal protectors for all motors
Motor oil-immersed heat dissipation
When the cable comes out, the standard length of the cable is 1.5 meters"

Sealing Level
"Shaft end adopts double seal design
The sealing protection level of the electric drum is IP66/67"

Oiling
"The electric drum has been filled with oil according to the standard before leaving the factory
Change oil every 50,000 hours of operation"

Other
"A backstop can be installed without affecting the shortest length of the cylinder horizontal installation
Belt speed and cylinder length can be made according to customers
According to customer requirements, various non-standard electric drums can be produced
CE safety certification of international authority"





DM113i-1*230V/50Hz
Power (kw/hp)	Number of Motor Stages	Gear Stages	Gear Ratio	Nominal Belt Speed(m/s)	Torque (Nm)	Traction (N)	Rated Current (A)	Minimum Length (mm)	Minimum Length weight (kg)
0.12/0.16	4	4	99.38	0.09	78.54	1390.24	0.84	320	12
			80.89	0.11	63.93	1131.58
			67.23	0.13	53.13	940.49
		3	60.60	0.14	47.89	847.74		300	10
			49.32	0.17	38.98	689.94
			41.00	0.21	32.4	573.55
			37.66	0.23	29.76	526.83
			31.65	0.27	25.01	442.76
			25.76	0.33	20.36	360.36
			21.41	0.40	16.92	299.51
		2	19.30	0.44	15.25	269.99
			15.71	0.55	12.42	219.77
			13.06	0.66	10.32	182.70
			12.00	0.71	9.48	167.87
0.18/0.24	4	3	60.60	0.14	71.84	1271.61	1.4	300	10
			49.32	0.17	58.47	1034.91
			41.00	0.21	48.61	860.33
			37.66	0.23	44.65	790.24
			31.65	0.27	37.52	664.13
			25.76	0.33	30.54	540.54
			21.41	0.40	25.38	449.26
		2	19.30	0.44	22.88	404.98
			15.71	0.55	18.62	329.65
			13.06	0.66	15.48	274.05
			12.00	0.71	14.23	251.80
0.23/0.31	4	3	49.32	0.17	74.71	1322.39	1.67	335	13.5
			41.00	0.21	62.11	1099.31
			37.66	0.23	57.05	1009.76
			31.65	0.27	47.94	848.61
			25.76	0.33	39.02	690.69
			21.41	0.40	32.43	574.05
		2	19.30	0.44	29.24	517.48
			15.71	0.55	23.80	421.22
			13.06	0.66	19.78	350.17
			12.00	0.71	18.18	321.75







1	front steel shaft	10	alloy steel gear shaft	19	motor wire lead
2	bearing sleeve	11	bearing	20	tie wraps
3	oil resistant seal	12	steel shell	21	front axle connecting sleeve
4	casting aluminumfront cover	13	motor stator core	22	inner hexagon screw
5	bearing	14	motor stator coil	23	casting aluminum back cover
6	annular gear	15	motor rotor	24	oil plug
7	inner hexagon screw	16	alloy steel gear shaft	25	steel rear axle
8	needle bearing	17	motor stator shell	26	cable protector
9	steel gear rack	18	motor castingaluminum back cover	27	Oil resistant wire

 Shell
The standard shell is made of low carbon steel. lt can be surface knurled orrubberized to increase the friction.Stainless steel 304 is for food grade.

 Shaft
The standard shaft is made of carbon steel. Stainless steel 304 is for food grade.

 Sealing cover
The standard sealing cover is made of die-casting Aluminum, it's also for food gradeand can be customized SS304 cover.

 Gear reducer
Planetary gear structure, solar gear and planetary gear to ensure the high torque output.MotorFrequency 50Hz /60Hz,

applicable to universal voltage. Electrical insulation: Grade fthe standard length of wire exposed is 1.2 meters.
 Seal up
The shaft ends are with the double seal design, the drum motors seal protectiongradeis lP66/67
 Oiling
Drum motors have been filled oil, change it after working 50,000 hours.e

 Others
The drum motors can be equipped with backstop, preventing from goods reverse orslip when the inclined conveyor stops. And no need to extend the length of electricrollers.
The drum motors can be equipped with electromagnetic brake, but the length will beextended. The speed and the shell length can be customized.We can OEM drum motors according to customer requirements.





Drum motors can be used for roller conveyors and belt conveyor. it is the new generation conveying meth-od.The installation of the drum motors is much easier and simple, which means lower cost of designing andpurchasing. Even under severe conditions, such as full of water, dust, chemicals, oil, grease and high pres.sure water washing, drum motors can work well. Because the motor, gearbox and bearings are installedinside of the drum, it saves lots of space. The most important is that it is safest for transporting equipments.
