Steel Conveyor Transfer Rollers
Conveyor transfer roller made of light duty conveyor roller and heavy duty conveyor roller, installed in conveyor diverter in sorting logistic roller conveyor with high speed. It made from material of carbon steel with certain thickness. The dimensions can be customized.
- Product Introduction
Products Description
Conveyor Transfer Roller
The conveyor transfer roller is available in both light-duty and heavy-duty configurations, designed for high-speed operation in conveyor diverters within sorting logistics roller conveyors. Constructed from carbon steel with a specified thickness, these rollers can be customized to meet specific dimensional requirements.
Galvanized Roller Conveyor Frame Materials
Frames are available in:
Carbon steel (spray-coated plastic)
Stainless steel
Aluminum profiles
For stacked material handling, a stacking roller configuration can be implemented.
Unpowered Galvanized Roller Conveyor
This type supports both single-row and stacked material conveying, offering flexibility in logistics operations.
Features of Conveyor Roller:
Bearing System:
Precision ball bearings with inner/outer sleeves for quiet, smooth operation.
Lubrication Options: Oil or grease (configurable).
Durability & Protection:
Sealed end caps prevent dust/water ingress.
Adapts to harsh environments (e.g., humidity, moderate contamination).
Speed & Capacity:
Max Speed: Up to 120 m/min (varies by roller diameter/length).
Load: Supports both light (e.g., parcels) and heavy-duty loads.
Operating Temperature: -5°C to +40°C.
Parameter of Steel Roller
| Product Name | D￠ (D) | Tube Length (L) | Material | Shaft￠ (d) | Shaft Material | Tube Thickness (T) | Bearing | Spring | Surface Treatment |
| Conveyor Transfer Roller | 25 | 150-300 | Sus, Carbon Steel | 8mm | Sus, Carbon Steel | 0.8mm 1.2mm 1.5mm 2.0mm 2.5mm 3.0mm 4.0MM Customized |
Machined Bearing, Punching Bearing | Spring | Zinc Plated Chromating Nickle Rubber Cover PVC Cover |
| 38 | 150-300 | 12mm | |||||||
| 50 | 150-300 | 12mm/15mm | |||||||
| 60 | 150-300 | 12mm/15mm/20mm | |||||||
| 76 | 150-300 | 15mm/20mm | |||||||
| 89 | 150-300 | 20mm/25mm | |||||||
| ★ Customized | ★ Load Capacity: 30-250KG/PC | ||||||||
Company Profile
Dongguan Smart Automation Part Co., Ltd originated from the year of 2002, located in Dongguan well known as the world factory center, owns over 8600m2 production center. Smart focus on R&D and production of automation parts especially drum motor, precision gear, conveyor roller, conveyor roller bearing, ball transfer unit, etc. So far, we have our own brand of Srollmart, which enjoy a good reputation in automation industry.
why choose us
With 20+ years of deep industry experience, wehave mastered advanced technology andmanufacturing processIn the 18 standardized production processes,we strictly implement 6 quality inspectionprocesses, strictly control every detail, toprovide enterprises with high performanceand high standard conveyor roller products.
High efficiency, energy saving,wear-resistant and durableUsing precision bearings, flexible rotationwithout jamming, saving time and effort.Special high frequency seamless weldedpipe, not only strong load capacity, but alsowear resistance.
A full range of models: We provide φ38, p50φ60, 76, φ89 and other types of rollermodels to meet the needs of different scenes,Various materials: carbon steel galvanized, 201stainless steel, 304 stainless steel, coatedchrome and other materials for you to choose,to meet the requirements of differentprocesses and environments.Length customization: We can customizerollers with a length of 100mm-2000mmaccording to the needs of different industriesand different processes.
Independent research and development ofautomatic special machine: The use ofindependent research and development ofautomatic special machine processing, toensure the stability and concentricity of rollerrotation, to provide you with high qualityproducts.Strong production service team: with18 equipment and 40 professional productionservice team to ensure production efficiencyand quality.Sufficient stock of raw materials: to meet theneeds of fast delivery, standard products wepromise to deliver within 7 days, saving youtime and cost.
